Drive train:
- On-demand 4 wheel drive (Switchable 2wd and 4wd – only use the 4wd when required saving tire wear, differential strain and fuel consumption, also reduce turning radius)
- Font Airlocking Differential
- 2 Speed PowerShift Auto Transmission (2-speed forward, 2-speed reverse)
- 25km/h Top speed
Dimension (LxWxH): 4375mm x 1585mm x 2150mm
Wheelbase: 1875mm
Total Weight:5800kg
Capacity: 3500kg
Engine: Xinchai 498BT
Type: 4 cylinder diesel
Power: 50HP
Lifting Height:
Standard 4.5m (Other height available)
Mast:
- Clear view mast provides excellent Vision
- 3 stage container mast with side-shift
- Comes with two extra hydraulic valves for other attachments
Control:
Hydraulic joystick or lever
Tilting rear bonnet and seat for ease of maintenance
These are the best value 4wd rough terrain forklifts on the market today.
We are the manufacturer of all of our listing products.
All of our machines come with:
- 24 Month / 2000 hour full parts & labour warranty
We offer Australian-wide delivery & warranty backup.
Competitive freight options and finance available.
SUMMIT Forklift, your specialist for rough terrain material handling.
Technical Specifications
- Dimension (LxWxH): 4375mm x 2100mm x 2150mm
- Length to fork carriage: 3300mm
- Wheelbase: 1875mm
- Total Weight: 5900kg
- Capacity: 3500kg
- Engine: Japanese Kubota V2403 50HP Diesel Engine
Type: 4 cylinder diesel
Power: 50HP - Lifting Height: Standard 4.5m (Other height available)
Optional Attachments
